Newly developed High Image Quality 32.5 megapixels APS-C sized CMOS sensor.
DIGIC X Image Processor with a native ISO range of 100-32000, expandable to 512008.
Dual Pixel CMOS AF II covering approximately 100% width and height with up to 651 zones down to EV -5.0.
High speed shooting 15fps mechanical, 30fps high speed electronic shutter, and RAW Burst Mode with ½ second pre-shooting.
Subject tracking inherited from the R3 with people, animal, and vehicle detection.
5-axis in-body Image Stabilization with auto-level technology.
High Image Quality with a 32.5 Megapixel (APS-C) CMOS Sensor
The EOS R7 features a newly developed and high image quality 32.5 Megapixel APS-C CMOS sensor. Designed for powerful and effective telephoto reach, it empowers fast continuous shooting with high-speed autofocus, so you can capture moment-by-moment images with clear and impressive detail.
High-Speed Shooting
Whether you’re shooting speeding cars, sports, wild animals, or just life as it happens, speed is on your side. The EOS R7 lets you shoot a fast 15 fps using mechanical shutter, up to 30 fps with the electronic shutter, and with RAW Burst Mode with ½ second pre-shooting, you can capture the perfect moment down to the split second.
Blazing Fast Autofocus
Capture fast moving images with accuracy and ease. Canon's highly responsive Dual Pixel CMOS AF technology uses every pixel on the imaging sensor to detect focus, covering approximately 100% width and height with up to 651 zones.
5-axis In-body Image Stabilization with Auto-Level Technology
The EOS R7 features an IBIS (In-Body Stabilization System) with up to 7 stops of shake correction with coordinated control IS. This can be a game changer for handheld videos and low light photography.
Record Each Clip Over 30 Minutes
Set up your video without worrying about it stopping after 30-minutes.
Optimized for Video
Get professional-grade 4K video on-the-go
Get professional-grade 4K video on-the-go with Movie Servo AF, an autofocus system that includes subject detection and subject tracking for quicker shooting and a stronger focus.
Product Specifications
Type
Type
Digital single-lens non-reflex AF/AE camera
Image Processor
DIGIC X
Recording Media
SD card SD card speed class-compatible. Compatible with UHS-II Eye-Fi cards and Multimedia cards (MMC) are not supported.
Compatible Lenses
Canon RF-S/RF lens group (excluding EF, EF-S and EF-M lenses) When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)
Lens Mount
Canon RF mount
Image Sensor
Type
CMOS sensor (compatible with Dual Pixel CMOS AF)
Effective pixels
Approx. 32.5 megapixels
Sensor Size
Approx. 22.3 x 14.8 mm
Pixel Size
Approx. 3.2 µm square
Total Pixels
Approx. 34.4 megapixels
Aspect Ratio
3:2 (Horizontal: Vertical)
Color Filter System
RGB primary color filters
Low Pass Filter
Installed in front of the image sensor, non-detachable
Dust Deletion Feature
Self Cleaning Sensor Unit Removes dust adhering to the low-pass filter. At power off only / Enable / Disable. Performed automatically (taking about approx. 2 sec. as indicated on the screen) or manually (taking about approx. 7 sec. as indicated on the screen). After manually activated cleaning, the camera will automatically restart (Power OFF to ON). When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected. Dust Delete Data acquisition and appending The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images. The dust coordinate data appended to the image is used by the EOS Canon Digital Professional Software to automatically erase the dust spots. Not available in focus bracketing, RAW burst mode, or multiple-exposure shooting. Manual cleaning (by hand)
Recording System
Recording Format
Compliant to Design rule for Camera File system 2.0 and Exif 2.31*. *Supports time difference information.
Image Format
Still: JPEG, HEIF, RAW, Dual Pixel RAW, Raw Burst, C-RAW (CR3); Movies: ALL-I*, IPB, IPB Light * Time-lapse movies only
3:2 Aspect Ratio Large/HEIF/RAW: 6960 x 4640 Medium: 4800 x 3200 Small 1: 3472 x 2320* Small 2: 2400 x 1600 4:3 Aspect Ratio Large: 6160 x 4640* Medium: 4256 x 3200* Small 1: 3072 x 2320* Small 2: 2112 x 1600* RAW: 6960 x 4640 16:9 Aspect Ratio Large: 6960 x 3904* Medium: 4800 x 2688* Small 1: 3472 x 1952* Small 2: 2400 x 1344* RAW: 6960 x 4640 1:1 Aspect Ratio Large: 4640 x 4640 Medium: 3200 x 3200 Small 1: 2320 x 2320 Small 2: 1600 x 1600 RAW: 6960 x 4640 Values for Recording Pixels are rounded to the nearest 100,000th. RAW/C-RAW images are generated at 3:2, with information added about the specified aspect ratio, and JPEG images are generated at the specified aspect ratio. These aspect ratios (M / S1 / S2) and pixel counts also apply to resizing. * Indicate an inexact proportion.
File Numbering
The following file numbers can be set: File numbering methods Continuous numbering The numbering of captured images continues even after you replace the card. Auto reset When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card.
RAW + JPEG / HEIF Simultaneous Recording
Simultaneous recording of any combination of RAW/C-RAW and JPEG/HEIF image-recording quality is supported.
Color Space
Selectable between sRGB and Adobe RGB
Picture Style
Auto Standard Portrait Landscape Fine Detail Neutral Faithful Monochrome User Defined 1-3
White Balance
Settings
Auto (Ambience priority/White priority) Day Light Shade Cloudy1 Tungsten light White fluorescent light Flash Custom2 (Custom WB) Color temperature 1Effective also in twilight and sunset. 2Setting method options include [Custom White Balance] and [Shoot to set WB].
Auto White Balance
Option between ambience priority and white priority settings.
White Balance Shift
Blue/amber bias: ±9 levels Magenta/green bias: ±9 levels Corrected in reference to the current WB mode's color temperature. Blue/amber and magenta/green shift can be set at the same time.
Viewfinder
Type
OLED color electronic viewfinder; approx. 2.36 million dots resolution
Coverage
Approx. 100% vertically and horizontally relative to the shooting image area (with image quality L, at approx. 22mm eyepoint).
Magnification / Angle of View
Approx. 1.15x / Approx. 33 degrees (with 3:2 display, an 50mm lens at infinity, -1 m--1)
Eye Point
Approx. 22mm (at -1 m-1 from the eyepiece lens end)
Dioptric Adjustment Range
Approx. -4.0 to + 2.0 m-1 (dpt)
Autofocus
Focus Method
Dual Pixel CMOS AF
Number of AF zones available for Automatic Selection
AF area: Horizontal: Approx. 100% x Vertical: Approx. 100%* Stills: Max. 651 zones (31 x 21) Movies: Max. 527 zones (31 x 17)
AF Working Range
EV -5 to 20 (f/1.2 lens*, center AF point, One-Shot AF, at room temperature, ISO 100) * Except RF lenses with a Defocus Smoothing (DS) coating.
Focusing brightness range@999br/> (in movie recording)
Full HD 29.97fps : EV -3.5 to 20 With an f/1.2 lens*, center AF point, One-Shot AF,at room temperature, ISO 100 * Except RF lenses with a Defocus Smoothing (DS) coating.
AF Methods
AF Method Whole area AF Spot AF 1-point AF Expand AF Area (Above, below, left and right/Around) Expand AF Area: Around Flexible Zone AF 1,2,3
Subject to Detect
People, Animals, Vehicles, No Priority * Available with [AF Area] set to Whole area AF
Focus mode switch
AF / MF Applies when an RF or RF-S lens without a focus mode switch is attached. When lenses with a focus mode switch are attached, the setting on the lens takes precedence.
Exposure Control
Metering Modes
Real-time metering with image sensor (384 [24x16 zone metering]) Evaluative metering Partial metering (approx. 6.0% of the area at the center of the screen) Spot metering (approx. 3.0% of the area at the center of the screen) Center-weighted average metering
Metering Range
Still Photo Shooting : EV -2 to 20 (at room temperature, ISO 100) Movie Recording: EV 0 to 20 (at room temperature, ISO 100)
Exposure Control Modes
Click here to view full specifications PDF
ISO Speed Range
Available ISO speeds; user-set Normal ISO 100-32000 (in 1/3- or 1-stop increments) Expanded H (equivalent to ISO 51200) For [Highlight tone priority], the settable ISO speed range will be ISO 200 to 32000. Expanded ISO cannot be set for HDR mode or during HDR PQ shooting. User-defined ISO range - still photo shooting ISO Speed Range ISO Speed Minimum L 100 - 32000 (in 1-stop increments) Maximum ISO 200 - H (51200) (in 1-stop increments) * Expanded ISO speeds are noted as being "equivalent" to these speeds. User-defined Auto ISO range - still photo shooting Auto Range ISO Speed Minimum ISO 100-25600 (in 1-stop increments) Maximum ISO 200-32000 (in 1-stop increments) ISO Auto details in still photo shooting Shooting Mode No Flash Using Flash Variable control of maximum ISO Auto limit for E-TTL Compatible lens Incompatible lens Creative Zone P ISO 100*1*2-32000*2 ISO 100**1*2-6400*2 ISO 100**1*2-6400*2 TV AV M B ISO 400*3 ISO 400*3 ISO 400*3 Basic Zone A+ ISO 100-6400 ISO 100-6400 ISO 100-1600 SCN Varies by shooting mode Creative Filters Varies by shooting mode *1 ISO 200 when [Highlight tone priority] is set to [Enable] or [Enhanced]. *2 Varies depending on [Maximum] and [Minimum] of [Auto range]. *3 If outside the setting range, changed to the value most close to ISO 400.
Exposure Compensation
Photo Movie Manual ±3 stops in 1/3- or 1/2-stop increments AEB ±3 stops in 1/3- or 1/2-stop increments
AE Lock
Auto AE lock The metering mode for AE lock after focus can be customized. User-applied AE lock In the Fv, P, Tv, Av and M modes, enabled with the AE lock button. (Press again to update.) Enabled in all metering modes.
Shutter
Type
Mechanical Electronic 1st-Curtain Electronic Shutter (1st and 2nd curtain - silent*) *Cannot be used in conjunction with the following functions: flash photography, HDR shooting, multiple exposures, Multi Shot Noise Reduction, AEB, HDR PQ, anti-flicker shooting, Dual Pixel RAW shooting, Digital Lens Optimizer [High]. * A shutter release sound is not generated. However, note that the sounds other than the shutter release sound (aperture, focusing lens drive sound/electronic sound, etc.) may be generated. * In electronic shutter shooting under conditions such as flash firing by other cameras or with fluores-cent lighting or other flickering light sources, a strip of light or banding due to the brightness difference may be recorded in the image.
Shutter Speeds
When [Mechanical] or [Elec. 1st- curtain] is set: 1/8000-30 sec, bulb When [Electronic] is set: 1/16000-30 sec.
X-sync Speed
Mechanical Shutter: 1/250 sec. Elec. 1st-curtain: 1/320 sec.
Shutter Release
Soft-touch electromagnetic release
Self Timer
10-sec. delay, 2-sec. delay
Shutter Lag Time
Mechanical Shutter Electronic 1st Curtain Electronic shutter Shutter-release time lag *Measured with shutter button pressed fully from half-pressed position Approx. 99ms Approx. 50 ms Approx. 50 ms Based on Canon testing standards.
Image Stabilization (IS mode)
Still Photo IS
In-body IS operation can be selected when using a non-IS lens. Always on Only for shot
5-axis Image Stabilization with RF/RF-S, EF/EF-S lenses
Click here to view full specifications PDF
EOS R7 coordinated In-Body Image Stabilizer Still Shooting performance with RF & RF-S lenses
Click here to view full specifications PDF
External Speedlite
E-TTL balance
Ambience priority, standard, flash priority
Compatible E-TTL Speedlites
Canon EX- and EL-series Speedlites
E-TTL II Flash Meterings
Evaluative (Face Priority) Evaluative Average
Slow Sync@999br> (P/Av modes)
Mechanical Shutter Electronic 1st curtain 1/250-30 sec. auto 1/320-30 sec. auto 1/250-1/60 sec. auto 1/320-1/60 sec. auto 1/250 sec. (fixed) 1/320 sec. (fixed)
Flash Function Menu
Provided for EX- and EL-series Speedlites
Flash Exposure Compensation
±3 stops in 1/3- or 1/2-stop increments
Continuous flash control
E-TTL each shot E-TTL 1st shot
Drive System
Drive Modes and Continuous Shooting Speed
Click here to view full specifications PDF
Still photo file size / Number of possible shots / Maximum burst for continuous shooting
Click here to view full specifications PDF
HDR Shooting - Still
HDR PQ Shooting
Disable / Enable * Can be used in conjunction with Auto Lighting Optimizer.
HDR PQ Shooting - Still
Recording format Bit depth Color sampling method HDR specification HEIF 10 bit YCbCr 4:2:2 Rec. ITU-R BT.2100 (PQ)
HDR PQ Shooting - Movie
Recording format Bit depth Color sampling method HDR specification MP4 10 bit YCbCr 4:2:2 Rec. ITU-R BT.2100 (PQ)
Video Shooting
Focusing
Dual Pixel CMOS AF II
Exposure Compensation
±3 stops in 1/3- or 1/2-stop increments
Canon Log
Canon Log 3
Temperature Warning
The camera warns of rising internal temperatures by means of icons and indicators. Click here to view full specifications PDF
Estimated Camera Recovery Time
Estimated recovery times are indicated below. These are affected by various factors such as ambient temperature, continued camera operation and the selected shooting resolution. The time until full record time is available, will vary with ambient temperature. Click here to view full specifications PDF
Movie Recording Format
Click here to view full specifications PDF
Estimated Recording Time and Data
Click here to view full specifications PDF
LCD Screen
Type
TFT color, liquid-crystal monitor
Monitor Size
3.0-inch (screen aspect ratio of 3:2)
Dots
Approx. 1.62 million dots
Coverage
Approx. 100% vertically/horizontally
Brightness Control
Manually adjustable to one of seven brightness levels
Coating
Anti-smudge coating applied. Anti-reflection coating not applied.
Item Still Photo Movie - Magnify zoom display 1.5x-10x (5 levels) - AF point display Yes - Grid display Off / 3x3 / 6x4 / 3x3+diag - Rating OFF / 1 to 5 Stars Select images / Select range / All images in folder / All images on card / All found images Image Search Search conditions Rating / Date / Folder / Protect / Type of file Protect Select images / Select range / All images in folder / Unprotect all images in folder / All images on card / Unprotect all images on card / All found images / Unprotect all found images Cloud RAW image processing Supported - RAW image processing Supported RAW Burst processing Supported HEIF -> JPEG Conversion Supported - Cropping Supported -
Highlight Alert
The white areas with no image data will blink.
Histogram
Brightness and RGB
Quick Control Function
Function
The Quick Control screen is accessed by pressing the Quick Control button during still photo shooting.
Image Protection and Erase
Protection
Single image (select image) Select range All images in a folder All images on card Image browsing and image search can be based on ratings. Ratings-based image selections also possible with DPP. All found images (only during image search)
Erase
Except protected images Select images to erase Select range All images in folder All images on card All found images (only during image search)
2.4 GHz band Frequency: 2412 to 2462 MHz Channels: 1 to 11 channels
Security
Connection Method Authentication Encryption Encryption Key Format and Length Camera Access Point WPA2/ WPA3-Personal AES ASCII 8 characters Open Disable Infrastructure Open WEP Hexadecimal 10 digits Hexadecimal 26 digits ASCII 5 characters ASCII 13 characters Disable Shared key WEP Same as WEP above WPA-PSKWPA2-PSKWPA3-Personal TKIP AES 1-127 characters
Communication with a Smartphone
Images can be viewed, controlled, and received using a smartphone. Remote control of the camera using a smartphone is possible depending on the Camera Connect specifications. Images can be sent to a smartphone. Firmware can be downloaded and saved to a card in the camera using Camera Connect.
Remote Operation Using EOS Utility
The camera can be controlled via Wi-Fii® using EOS Utility.
Print from Wi-Fi® Printers
Supported.
Send Images to a Web Service
Still photos (RAW, C-RAW, HEIF, and JPEG) and movies (MP4) can be uploaded to image.canon server album. With the image.canon server, images can be sent to social media or a photo album link can be sent (by the image.canon specifications).
Cloud RAW Image Processing via image.canon (firmware 1.1.0 or higher)
Still RAW photos can be transferred to image.canon for RAW development using Deep Learning technology resulting in clearer images without losing detail through the reduction of noise, false color, moiré and jagged lines. *This feature requires a paid subscription (service begins July 25, 2022).
Bluetooth®
Standards Compliance
Bluetooth Specification Version 4.2 compliant (Bluetooth low energy technology)
Transmission Method
GFSK modulation
Customization
Custom Functions
Customizable Dials Still photo Movie Shutter button (half-press) Yes - Movie shooting button Yes - Multi-function () button Yes Yes ISO speed button Yes Yes AF-ON button Yes Yes AE lock (<*>) button Yes Yes AF point button Yes Yes DOF preview button Yes Yes Lens function () button Yes Yes Cross keys: Up button Yes Yes Cross keys: Left button Yes Yes Cross keys: Right button Yes Yes Cross keys: Down button Yes Yes Set button Yes Yes Multi-controller Yes Yes
Custom Dials
Main dial Quick control dial Control ring
My Menu Registration
Up to six top-tier menu items and Custom Functions can be registered. Up to five My Menu tabs can be added. My Menu tab overall operations Adding a tab Deleting tabs in a batch Deleting all tab items Setting the menu display My Menu tab detailed operations Selecting a registered item Sorting registered items Deleting selected registered items Deleting registered items in a batch Deleting tabs Changing a tab name (16 ASCII characters)
Interface
USB Terminal
Equivalent to Superspeed PLus USB (USB 3.2 Gen 2) For PC communication Terminal type: USB Type-C Shared with terminal for in-camera charging with USB Power Adapter PD-E1. In-camera Charging: Equivalent to USB type-C (5 V/1.5 A), but use should be restricted to USB Power Adapter PD-E1.
Video Out Terminal
HDMI micro OUT terminal Type D (Resolution switches automatically) / CEC not compatible Images can be displayed through the HDMI output and on screen at the same time. Images will not be displayed unless [NTSC] or [PAL] is properly set according to the video system of the TV set.
Clean HDMI output
Provided
Microphone Input Terminal
3.5mm diameter stereo mini jack
Headphone Terminal
3.5mm diameter stereo mini jack
Remote control terminal
Remote Switch RS-60E3 type terminal supported
Wireless remote control
Compatible with the Wireless Remote Control BR-E1 Compatible with infrared remote controls such as Remote Controller RC-6
Multi-function shoe
Supported
Power Source
Battery
LP-E6NH/LP-E6N/LP-E6* With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible. With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible.
Battery Check
Automatic battery check when the power switch is turned ON. Displayed in 6 levels on top LCD panel. Battery level can be checked on the LCD panel and in the viewfinder. Battery Info display in Set-up Menu: Type of power source used. Remaining capacity (percentage of battery charge remaining). Recharge performance: (3-level display of battery's ability to hold a charge)
Start-up Time
Approx. 0.4 sec. Based on CIPA testing standards.
Dimensions and Weight
Dimensions (W x H x D)
Approx. 5.20 x 3.56 x 3.61 in. / 132.0 x 90.4 x 91.7 mm Based on CIPA standards.
Weight
Approx. 1.1 lbs (18.70 oz) Body Only Approx. 1.3 lbs (21.59 oz) With battery,and memory card
